Triangles - Area through inradius and circumradius

Upon drawing a rough sketch of the coordinates given, we realise that this is a right-angled triangle.

The three side lengths are 6, 8 and 10 units

The inradius of a circle can be calculated using the formula: $$rs=Area$$, where s is the semi-perimeter of the triangle

The Area would be $$\frac{1}{2}\times\ 6\times\ 8=24$$
and the semi-perimeter would be $$\frac{10+6+8}{2}=12$$

Giving the inradius to be $$\frac{24}{12}=2$$ units

Therefore, 2 is the correct answer.

Let x be the value of third side of the triangle. Now we know that Area = 17.5*9*x/(4*R), where R is circumradius.

Also Area = 0.5*x*3 .

Equating both, we have 3 = 17.5*9 / (2*R)

=> R = 26.25.

By Pythagoras theorem we get BC = 25 . Let BD = x

Triangle ABD is similar to triangle CBA => AD/x = 20/15

Also triangle ADC is similar to triangle ABC => AD/(25-x) = 15/20

From the 2 equations, we get x = 9, DC = 16 and AD = 12

We know that AREA = (semi perimeter ) * inradius

For triangle ABD, Area = 1/2 x BD X AD = 1/2 x 9 x 12 = 54 and semi perimeter = (15 + 9 + 12)/2 = 18. On using the above equation we get, inradius, r = 3.

Similarly for triangle ADC we get inradius R = 4 .

PQ = R + r = 7 cm
