An archer, from the point A, is aiming at a target, placed on the top of a 56 feet tall tree. The base of the tree is at the point C. From the archer’s position, the angle of elevation to the target is 45° from his eye level. The archer, facing the tree, moves backwards on the straight line joining the points A and C, to a new position at the point B. From the point B, the angle of elevation from his eye level to the target becomes 30°.
How far did the archer move from A to B (in feet) if his eye level is at a height of 6 feet from the ground?
Let the tree be PC and the archer be RA.
Given : Height of the tree = 56ft, height of the archer up to the eye level = 6ft, angle of elevation at point A = 45$$^{\circ\ }$$, angle of elevation at point B = 30$$^{\circ\ }$$
To find : Length of AB
In $$\triangle\ $$PQR, $$\tan\ 45^{\circ\ }=\ \frac{\ PQ}{QR}=\ \frac{\ 50}{QR}$$
QR = 50ft (as $$\tan\ 45^{\circ\ }=\ 1$$)
Now, in $$\triangle\ PQS$$,
$$\tan\ 30^{\circ\ }=\ \frac{\ PQ}{QS}=\ \frac{\ PQ}{QR+RS}=\ \frac{\ 50}{50+RS}$$
$$\ \frac{\ 1}{\sqrt{3\ }}=\frac{\ 50}{50+RS}$$
RS = $$50\left(\sqrt{3\ }-1\right)$$ ft
Since RS = AB, AB = $$50\left(\sqrt{3\ }-1\right)$$ ft
Hence, the length of AB is $$50\left(\sqrt{3\ }-1\right)$$ feet
$$\therefore\ $$ The required answer is C.
