Question 18

In the adjoining figure, two rectangles and two right-angled triangles are arranged as shown. The numbers shown inside each are their respective areas. Then the area of $$A$$ is



Correct Answer: 48

Solution

Share

Let the left and right widths be $$w_1,w_2$$ and the upper and lower heights be $$h_1,h_2$$.


The areas of the regions are as follows

$$w_1h_1=72$$, $$\dfrac{1}{2}w_2h_1=48$$ and $$w_2h_2=128$$.

Hence $$w_1h_2=\dfrac{(w_1h_1)(w_2h_2)}{w_2h_1}=\dfrac{72 \times 128}{96}=96$$.

Therefore, $$A=\dfrac{1}{2}w_1h_2=48$$.
