Question 50

Following figure shows spectrum of an ideal black body at four different temperatures. The number of correct statement/s from the following is _____.


A. $$T_4 > T_3 > T_2 > T_1$$
B. The black body consists of particles performing simple harmonic motion.
C. The peak of the spectrum shifts to shorter wavelength as temperature increases.
D. $$\frac{T_1}{\nu_1} = \frac{T_2}{\nu_2} = \frac{T_3}{\nu_3}$$
E. The given spectrum could be explained using quantisation of energy


Correct Answer: 2

Solution

Share
  • Statement A: $$T_4 > T_3 > T_2 > T_1$$
    Analysis: According to Stefan-Boltzmann law and Wien's displacement law, as the temperature of a black body increases, its peak intensity increases, and the peak wavelength shifts to the left (shorter wavelengths). Looking at the provided graph, the topmost curve represents the highest temperature, meaning $$T_1 > T_2 > T_3 > T_4$$.

    Status: Incorrect

    • Statement B: The black body consists of particles performing simple harmonic motion.
      Analysis: This was a classical mechanics assumption (treating atoms as continuous classical harmonic oscillators), which famously failed to describe the experimental curve, leading to the "ultraviolet catastrophe."

      Status: Incorrect

      • Statement C: The peak of the spectrum shifts to shorter wavelength as temperature increases.
        Analysis: This is the precise statement of Wien’s Displacement Law, which states that the peak wavelength ($$\lambda_{\text{max}}$$) is inversely proportional to the absolute temperature ($$T$$):

        $$\lambda_{\text{max}} \cdot T = \text{constant}$$
        Status: Correct

        • Statement D: $$\frac{T_1}{\nu_1} = \frac{T_2}{\nu_2} = \frac{T_3}{\nu_3} \neq \text{constant}$$
          Analysis: Since $$\nu = \frac{c}{\lambda}$$, Wien’s Displacement Law can be expressed in terms of frequency as $$\frac{\nu_{\text{max}}}{T} = \text{constant}$$. Rearranging this gives $$\frac{T}{\nu_{\text{max}}} = \text{constant}$$. The statement falsely claims that this ratio is not a constant.

          Status: Incorrect

          • Statement E: The given spectrum could be explained using quantisation of energy.
            Analysis: Max Planck successfully explained the complete black-body radiation curve by postulating that energy is emitted or absorbed in discrete packets called quanta ($$E = nh\nu$$).

            Status: Correct

            • The correct statements are C and E.

            Final Answer: 2
