In the adjoining figure $$\angle DCE = 10^\circ$$, $$\angle CED = 98^\circ$$, $$\angle BDF = 28^\circ$$.
Then the measure of angle $$x$$ is
In $$\triangle CDE$$
$$\angle CDE = 180\degree -Β \angle DCE -\angle CED =180\degree - 10\degree - 98\degree = 72\degree$$
Since ABCD is a cyclic quadrilateralΒ
$$\angle BAD + \angle BCD = 180\degree $$Β
$$\angle FAB = \angle FDB =28\degree$$ (Angles subtended by the same chord at different points on the circle)
Now, in quadrilateral GACE,
$$x + \angle FAB +Β \angle BAD + \angle BCD + \angle DCE+ \angle DEC =360\degree$$ (Angle sum property)
$$ x = 360\degree- (28\degree+ 180\degree+10\degree + 98\degree ) =44\degree$$
