A alternating current at any instant is given by $$i = [6 + \sqrt{56}\sin(100\pi t + \pi/3)]\ A$$. The rms value of the current is ______ A.
Correct Answer: 8
The current is $$i = 6 + \sqrt{56}\sin(100\pi t + \pi/3)$$
This is a DC component plus an AC component.
DC component: $$I_{DC} = 6$$ A
AC peak value: $$I_0 = \sqrt{56}$$ A
RMS of AC component: $$I_{AC,rms} = \frac{\sqrt{56}}{\sqrt{2}} = \sqrt{28}$$ A
Total RMS: $$I_{rms} = \sqrt{I_{DC}^2 + I_{AC,rms}^2} = \sqrt{36 + 28} = \sqrt{64} = 8$$ A
The answer is 8.
