A wire having a linear mass density $$9.0 \times 10^{-4}$$ kg m$$^{-1}$$ is stretched between two rigid supports with a tension of 900 N. The wire resonates at a frequency of 500 Hz. The next higher frequency at which the same wire resonates is 550 Hz. The length of the wire is _________ m.
Correct Answer: 10
We start by recalling that a stretched wire fixed at both ends behaves like a stretched string. For such a string the resonant (natural) frequencies are given by the well-known formula
$$f_n \;=\; \frac{n\,v}{2L}, \qquad n = 1,2,3,\dots$$
Here $$f_n$$ is the $$n^{\text{th}}$$ resonant frequency, $$v$$ is the speed of transverse waves on the wire and $$L$$ is the length of the wire.
For two consecutive resonant frequencies, say $$f_n$$ and $$f_{n+1}$$, we have
$$f_{n+1} - f_n \;=\; \frac{(n+1)v}{2L} \;-\; \frac{n\,v}{2L} \;=\; \frac{v}{2L}.$$
This shows that the difference between any two successive resonant frequencies is always $$\dfrac{v}{2L}$$, independent of the harmonic number.
According to the data, the wire resonates at $$500\;\text{Hz}$$ and the next higher frequency is $$550\;\text{Hz}$$. Hence
$$f_{n+1} - f_n \;=\; 550 - 500 \;=\; 50\;\text{Hz}.$$
Using the relation for consecutive differences, we write
$$\frac{v}{2L} \;=\; 50.$$
To find $$v$$ we employ the formula for the speed of transverse waves on a stretched string:
$$v \;=\; \sqrt{\frac{T}{\mu}},$$
where $$T$$ is the tension and $$\mu$$ is the linear mass density of the wire.
The given tension is $$T = 900\;\text{N}$$ and the linear mass density is $$\mu = 9.0 \times 10^{-4}\;\text{kg m}^{-1}$$. Substituting these values, we obtain
$$v \;=\; \sqrt{\frac{900}{9.0 \times 10^{-4}}}.$$
Dividing inside the square root, we get
$$\frac{900}{9.0 \times 10^{-4}} \;=\; \frac{900}{0.0009} \;=\; 1\,000\,000.$$
Taking the square root,
$$v \;=\; \sqrt{1\,000\,000} \;=\; 1000\;\text{m s}^{-1}.$$
Now we substitute this value of $$v$$ into the difference equation $$\dfrac{v}{2L}=50$$:
$$\frac{1000}{2L} \;=\; 50.$$
Simplifying the numerator first:
$$\frac{1000}{2} \;=\; 500,$$
so the equation becomes
$$\frac{500}{L} \;=\; 50.$$
Cross-multiplying gives
$$500 \;=\; 50\,L.$$
Dividing both sides by $$50$$, we find
$$L \;=\; \frac{500}{50} \;=\; 10\;\text{m}.$$
So, the answer is $$10\;\text{m}$$.
