Question 21

A hanging mass $$M$$ is connected to a four times bigger mass by using a string pulley arrangement, as shown in the figure. The bigger mass is placed on a horizontal ice-slab and being pulled by $$2Mg$$ force. In this situation, tension in the string is $$\frac{x}{5}Mg$$ for $$x =$$ ______. Neglect mass of the string and friction of the block (bigger mass) with ice slab.



Correct Answer: 6

Let us start by considering the forces on the 4M block

There is an external Force pulling it which is $$F=2Mg$$ and $$T\left(tension\ of\ the\ rope\right)$$

we know that here masses M and 4M have the same acceleration , lets take it as 'a'

now writing equation for the 4M block

$$2Mg\ -\ T\ =4Ma$$

and for the M block

Forces at $$T\left(tension\ of\ the\ rope\right)$$ and $$F=Mg$$(due to gravity)

now writing equation for M block

$$T-Mg=Ma$$

now on adding these both equations

$$2Mg-Mg=5Ma$$

$$Mg=5Ma$$

$$\frac{g}{5}=a$$

Now substituting value of a in equation 1

$$2Mg\ -\ T\ =4M\times\ \frac{g}{5}$$

$$2Mg\ -\frac{4Mg}{5}\ =T$$

$$\frac{\left(10Mg\ -4Mg\right)}{5}\ =T$$

$$\frac{6Mg}{5}\ =T$$

Therefore x=6
