A ray of light passing through an equilateral prism is having velocity $$2.12 \times 10^8$$ m/s in the prism material, then the minimum angle of deviation is _______ degrees.
speed of light in medium:
v = c / n
so refractive index:
n = c / v = (3 × 10⁸) / (2.12 × 10⁸) ≈ 1.415
for equilateral prism:
A = 60°
at minimum deviation:
$$n=\frac{\sin\left(\frac{A+\delta_m}{2}\right)}{\sin\left(\frac{A}{2}\right)}$$
$$\sin\left(\frac{A}{2}\right)=\sin30°=0.5$$
so:
$$n=\frac{\sin\left(\frac{60+\delta_m}{2}\right)}{0.5}$$
$$\sin\left(\frac{60+\delta_m}{2}\right)=\frac{n}{2}\approx0.7075$$
$$\frac{60+\delta_m}{2}\approx45°$$
$$60+\delta_m\approx90°$$
$$\delta_m\approx30°$$
