Question 38

Refer to the figure given below, current between terminals $$A$$ and $$B$$ is _______A.


Solution

Share

Step -1

upper 3  branches have 3 batteries of emf 5 volt each and 3 resistors each of 3 ohm.

so by parallel combination it will be effectively 15 volts and 3 ohm which is connect to last branch ( 3 resistor of 3 ohm each) which had equivalent resistance 9 ohm.

so current = 15/(3+9) = 1.25 A
