A hole is drilled in a metal sheet. At 27 °C, the diameter of hole is 5 cm. When the sheet is heated to 177 °C, the change in the diameter of hole is $$d \times 10^{-3}$$ cm. The value of $$d$$ will be _____, if coefficient of linear expansion of the metal is $$1.6 \times 10^{-5} /°C$$

We need to find $$d$$ where the change in diameter is $$d \times 10^{-3}$$ cm when temperature changes from 27°C to 177°C.

Given data.

Initial diameter $$D_0 = 5$$ cm, $$\alpha = 1.6 \times 10^{-5}$$ /°C, $$\Delta T = 177 - 27 = 150$$°C.

Apply linear expansion.

When a metal sheet with a hole is heated, the hole expands as if it were filled with the same metal.

$$\Delta D = D_0 \times \alpha \times \Delta T = 5 \times 1.6 \times 10^{-5} \times 150$$

$$= 5 \times 2.4 \times 10^{-3} = 12 \times 10^{-3}$$ cm

Conclusion.

$$d = 12$$.

Therefore, the answer is 12.
