A bead of mass 'm' slides without friction on the wall of a vertical circular hoop of radius 'R' as shown in figure. The bead moves under the combined action of gravity and a massless spring ( k ) attached to the bottom of the hoop. The equilibrium length of the spring is 'R'. If the bead is released from top of the hoop with (negligible) zero initial speed, velocity of bead, when the length of spring becomes ' R ', would be (spring constant is 'k', g is accleration due to gravity

When the length of the spring becomes R, the angle spring will form from the vertical will be $$\theta\ =60^{\circ\ }$$.

Since all forces acting on the body are conservative, total energy remains conserved.

Potential energy of the bead at the top due to gravity, $$PE_{g}=mg\left(2R\right)=2mgR$$

Potential energy of the bead at the top due to the spring, $$PE_{sp}=\frac{1}{2}kx^2\ =\frac{1}{2}k\left(2R-R\right)^2=\frac{1}{2}kR^2$$

⇒ Initial potential energy, $$PE_{initial}=PE_g+PE_{sp}=2mgR+\frac{1}{2}kR^2$$

When spring becomes the length R, the extension in the spring becomes 0. Therefore, Potential energy = gravitational potential energy

Final potential energy, $$PE_{final}=mgH_{final}\ =\ mg\left(R\cos60^{\circ\ }\right)=\frac{mgR}{2}$$

Loss in potential energy = Gain in kinetic energy

$$KE_{final}-KE_{initial}=PE_{initial}-PE_{final}$$

⇒ $$KE_{final}=PE_{initial}-PE_{final}\ =\ 2mgR+\frac{1}{2}kR^2-\frac{mgR}{2}=\frac{3}{2}mgR+\frac{1}{2}kR^2$$

$$\frac{1}{2}mv^2=\frac{3}{2}mgR+\frac{1}{2}kR^2$$

$$\therefore\ v=\sqrt{\ 3gR+\frac{kR^2}{m}}$$
