Question 25

An electron is moving under the influence of the electric field of a uniformly charged infinite plane sheet $$S$$ having surface charge density $$+\sigma$$. The electron at $$t = 0$$ is at a distance of $$1$$ m from $$S$$ and has a speed of $$1$$ m s$$^{-1}$$. The maximum value of $$\sigma$$, if the electron strikes $$S$$ at $$t = 1$$ s is $$\alpha \left[\frac{m\varepsilon_0}{e}\right] \frac{C}{m^2}$$. The value of $$\alpha$$ is _______.

Correct Answer: 8

Take away from sheet as positive.

Then electron starts moving away:

u=1

Displacement to reach sheet:

s=−1

Acceleration is toward sheet, hence negative:

$$a=-\frac{e\sigma}{2m\epsilon_0}$$

Using

$$s=ut+\frac{1}{2}at^2$$

with t=1,

$$-1=1+\frac{1}{2}a$$

$$\frac{a}{2}=-2$$

a=−4

Now

$$-\frac{e\sigma}{2m\epsilon_0}=-4$$

$$\frac{e\sigma}{2m\epsilon_0}=4$$

$$\sigma=8\frac{m\epsilon_0}{e}$$
